from $ 32,994.50 GST Incl.
With optimised ease and efficiency, you can print directly onto accessories, giftware, ceramics, and countless other popular products. Create unique, desirable and highly-profitable custom items with the VersaUV LEF2-200 flatbed UV printer that offers brilliant colour results, realistic textures and stylish embossed effects.
Print gloss/matte finishes, realistic textures, or 3D embossed effects to add an irresistible new dimension of “touch and colour”. Create your own special finishes or choose from seventy-two ready-to-use texture patterns in our Roland Texture System Library.
leaves texture printed lef2-200leather texture printed on LEF2-200metal texture printed on LEF2-200Wood texture printed on an LEF2-200Lace texture printed on an LEF2-200Stitching texture printed on an LEF2-200
Print graphics with consistent colour and incredible detail on a virtually unlimited range of promotional products.
With state-of-the-art, low-heat UV-LED lamps, and self-wicking ink features, the fully-enclosed LEF2-200 flatbed UV printer is simple-to-operate and runs clean and cool with a safeguarded operation. In addition to eliminating additional machine movements of previous models to give you a more efficient operation, it offers new machine advantages to streamline your print process.
Built to provide years of reliable service – even in the most demanding print environments – Roland DG’s wide format printers come with a 1, 3 or 5 Year Warranty.
Roland DG has earned a reputation for long-lasting, high-performance devices, backed by first-rate customer service. This support includes expert technical assistance, videos and free Roland software updates for the lifetime of the machine.
Roland DG's international ISO certifications are your assurance of quality products and service.
|Printing method||Piezo ink-jet method|
|Attachable objects to be printed on - Width||Max. 538 mm|
|Attachable objects to be printed on - Length||Max. 360 mm|
|Attachable objects to be printed on - Thickness||Max. 100 mm|
|Attachable objects to be printed on - Weight||Max. 5kg|
|Maximum printing width / printing length||Max. 508 (width) × 330 (length) mm|
|Ink - Type||ECO-UV (EUV, EUV4) 220 ml cartridge|
|Ink - Colors||Five colours (cyan, magenta, yellow, black, and white)
Five colours (cyan, magenta, yellow, black, and white) and primer
Six colours (cyan, magenta, yellow, black, white, and gloss)
|Ink-curing unit||Built-in UV-LED lamp|
|Print resolution (dots per inch)||Max. 1440 dpi|
|Distance accuracy*||Error of less than +/-0.3% of distance traveled or +/-0.3 mm (+/-11.8 mil), whichever is greater.|
|Connectivity||Ethernet (10BASE-T/100BASE-TX, automatic switching)|
|Power-saving function||Automatic sleep feature|
|Power requirements||AC 100 to 240 V ± 10%, 1.8 A, 50/60 Hz|
|Power consumption - During operation||Approx. 149 W|
|Power consumption - Sleep mode||Approx. 13 W|
|Acoustic noise level - During operation||60 dB (A) or less|
|Acoustic noise level - During standby||49 dB (A) or less|
|Outer dimensions||1,202 (W) × 962 (D) × 549 (H) mm|
|Environment - During operation||Temperature: 20 to 32°C (22°C or higher recommended)
Humidity: 35 to 80% RH (no condensation)
|Environment - Not operating||Temperature: 5 to 40°C
Humidity: 20 to 80% RH (no condensation)
|Included items||Power cord, software RIP, cleaning liquid, drain bottle, manuals, etc.|
|Max. Print Area||305 x 280 mm||508 x 330 mm||770 x 330 mm|
|Max. Media (Width x Depth x Thickness)||335 x 310 x 100 mm||538 x 360 x 100 mm||800 x 360 x 100 mm|
|Max Media Weight||5 kg||5 kg||8 kg|
|Ink Configuration Options||CMYK + Clear (gloss) + White||
With its ability to print CMYK, White and Clear inks directly around the curves and contours of three-dimensional objects, the LEF2-200 is ideally suited for personalising pens, golf balls, key chains and other promotional items. Variable data printing allows you to individualise each item with names, photos and other custom design elements.
Low-heat LED curing systems make the LEF2-200 ideal for printing on sensitive electronic devices, including tablets and smartphones. High-opacity White ink produces bright, crisp white text and graphics, and can also be printed as an undercoat to enhance full-colour graphics on clear acrylics and darker plastics.
With the LEF2-200, you can print directly on gift items ranging from jewelry and accessories to photo frames, wedding favors, dishware and even fabric items such as leather wallets and purses. Add interesting patterns and textures to your designs with layers of Gloss ink in matte or gloss.
*requires rotary accessory
The LEF2-200 is the perfect addition to awards and recognition businesses, allowing these shops to add full-colour graphics to engraved items for high-impact results. White ink allows you to print on clear acrylic awards as well as dark-colored plaques. Gloss ink adds elegant embossing and varnishing effects for a premium presentation.
Consumer and Industrial Products
For product designers, entrepreneurs and marketing professionals, the LEF2-200 customises a wide variety of products from toys and sports items to cosmetic cases and control panels. Variable data printing allows you to mark each product or part with individual serial and lot numbers.
With the LEF2-200, you can create a wide range of specialised signs for objects such as car doors, windows and interior spaces. Print directly on wood and other specialty materials for a truly unique look.
Automatic Printhead Cleaning
Automatically complete the setup operation of printhead cleaning and white ink circulation, so you can begin printing immediately after loading items— an auto wake-up feature acts like an alarm clock, alerting your LEF2-200 to start these cycling procedures.
Included VersaWorks 6 RIP Software
The latest edition features powerful new 64-bit processing and RIP capabilities, plus the easy cropping, tiling, nesting, and other advantages of the world’s most popular RIP software.
New features include new print queue options, UV post cure within the RIP, and 16-pass print mode (standard 720x720)
More Efficent Reprinting
The LEF2 Series adopts a Multiple Print function that can perform continuous printing efficiently. Previously, when printing the same data continuously, it was necessary to send print data from the included software each time when loading materials. Now with the Multiple Print function, you can perform the next print just by pressing the start button on the machine withour returning to the software.
